Comparative Architectures 2006-07
Principal lecturer: Dr David Greaves
Taken by: Part II
Syllabus
Past exam questions
Example Classes
The three classes will be at 2:00pm in FW26 on 26, 28, 2nd Feb/Mar 2007.
Topics
Please note: Because time ran out in the last lecture, the material
from the end of Section 7 that was only briefly covered (on weak memory
ordering, memory barrier instructions and atomic instructions) is not
examinable this year.
Lecture Notes
The lecture notes are in seven PDF files:
Section 1
- * Instruction set architectures. ISA history and compatibility, illustrated with IBM 360 and notable 8, 16, 32, 64 microprocessors. Review of stack/accumulator/GPR instruction sets in terms of byte sex, load-store versus register-memory, addressing modes, sub and un-aligned memory support. [3++ lectures]
COMPARCH-1.pdf
ADDITIONAL MATERIAL
Section 2
- * Comparing architectures. Moore's Law, System versus chip performance. Performance metrics MIPS, MHz, FLOPS, SPEC. Power. Price. Compatibility [1+ lecture]
COMPARCH-2.pdf
ADDITIONAL MATERIAL
Section 3
- * Advanced pipelining. The CPU performance equation. Structural hazards: long latency instructions. Data hazards: result forwarding and delayed loads. Control hazards: branch prediction, trace caches and avoiding branches. Exceptions. [3 lectures]
COMPARCH-3.pdf
ADDITIONAL MATERIAL
Section 4
- * Super-scalar techniques. Instruction Level Parallelism (ILP). Dynamic out-of-order execution: Tomasulo, embedded dataflow, virtual registers. [2 lectures]
COMPARCH-4.pdf
ADDITIONAL MATERIAL
Section 5
- * Beyond super-scalar. The limits of ILP. Alternative architectures: VLIW processors and custom VLIW synthesis, Tri-media, SMT, SCMP [2 lectures]
COMPARCH-5.pdf
ADDITIONAL MATERIAL
Section 6
- * Memory hierarchy. Cache configurations. Latency versus bandwidth. Re-ordering and coherence. Programming for caches. [2 lectures]
COMPARCH-6.pdf
ADDITIONAL MATERIAL
Section 7
- * Multi-processor systems. Multi-core devices, multi-processor cache coherency. Interconnects for NUMA, message passing clusters and network on chip: OCP, ARM AXI. Models for weak memory ordering. [2 lectures]
COMPARCH-7.pdf
ADDITIONAL MATERIAL
The lecturing time allocated to each section is only nominal.
Sources Cited by Dr Greaves
The 'additional material' is currently not
allocated to specific lectures but will become so.
All other materials: see the ALL subdirectory for now.
Sources Cited by Dr Pratt
Sources of extra information and interesting articles:
|
